WP23TM24-02
BG Nexus Storm, IP66 Weatherproof 13A Single Socket with Mechanical Timer Control
Weather and dust protection - IP66 (with cover closed)
Fast fix - no separate screws, no screw covers, 150ยบ rotation
24 hour mechanical timer - 1 segment = 15 minutes, with override switch
Large open/closer paddles for easier operation
Patented cable entry - prevents accidental opening
LED power indicator mean the power status is visible even when the cover is down
Multiple knockouts for versatility when installing - 8 x 20mm
Angled in-line colour coded terminals with captive screws provide easy access for quick installation
Twin earth fitted as standard for high integrity circuits
Lockable hinged cover
| General Colour | Grey |
| Captive Terminal Screws | Yes |
| Backed-out Terminal Screws | Yes |
| Minimum Box Depth (mm) | N/A |
| Terminal Capacity (mm²) | 3 x 2.5mm² |
| Front Plate Insert Colour | White |
| Anti-fingerprint Lacquer | No |
| Anti-microbial Property | No |
| Fixing Screws Supplied | No |
| Number of Earth Terminals | 1 |
| Terminal Arrangement | Angled-in line terminals |
| Terminals with Colour Coding Print | Yes |
| Number of Sockets | 1 |
| Socket Type | G-3P UK Ireland Hong Kong 220-240V 13A |
| Number of Switches | 0 |
| Screw Caps | Yes |
| Switch Type (Ways & Poles) | N/A |
| IP Rating | IP66 |
| Operating Voltage (V) | 220-240 |
| Warranty (years) | 25 |
