MC522ARCD-01
BG Metal Clad 13A Double Switched Socket with Integrated Latching Type A RCD
13A Rated
Type A RCD
A rugged scratch resistant range, suitable for everyday use in commercial and industrial environments
Mounting box with 1 x 20mm knockout in each side and rear face
Latched (passive) version if set, will retain closed contacts if the mains supply is interrupted – essential for appliances like fridge freezers
No need to reset after a loss of power
Angled in-line terminals for easy access
Captive screws prevent screw loss
Twin earth fitted as standard for high integrity circuits
Flat profile with rounded edges
| General Colour | Grey |
| Captive Terminal Screws | Yes |
| Backed-out Terminal Screws | Yes |
| Minimum Box Depth (mm) | N/A |
| Terminal Capacity (mm²) | 3 x 4mm² |
| Anti-microbial Property | No |
| Fixing Screws Supplied | Yes |
| Number of Earth Terminals | 2 |
| Terminal Arrangement | Angled-in line terminals |
| Terminals with Colour Coding Print | No |
| Number of Sockets | 2 |
| Number of Switches | 2 |
| Screw Caps | No |
| Switch Type (Ways & Poles) | Single Pole |
| Fixing Centres (mm) | W-120.6 |
| IP Rating | IP20 |
| Rated Sensitivity (mA) | 30mA |
| RCD Mechanism Type | Latching |
| Trip Speed (mS) | <40ms |
| RCD Type | Type A |
| Operating Voltage (V) | 250 |
| Warranty (years) | 25 |
