R14C-01
2 way, retractive, printed PRESS, centre off
Simple secure 'locate & clip' fitting to frame
2 way retractive switch with 'press' written on the switch
Centre off position for dual circuit control
Captive backed out terminal screws for fast installation
Module to be installed with Grid frame and plate
Single pole
BG Electrical are confident in the quality of our workmanship and materials, the guarantee stated applies from the date of delivery. Please see our terms and conditions for more details
Dimensions
| Unpacked Height (mm) | 54 |
| Unpacked Width (mm) | 24.8 |
| Unpacked Depth (mm) | 25.8 |
| Minimum Box Depth (mm) | 25 |
| Front Plate Material Thickness (mm) | N/A |
Pack
| Packed Width (mm) | 75 |
| Packed Depth (mm) | 28 |
| Packed Height (mm) | 110 |
| Packed Gross Weight (kg) | 0.023 |
| Package Pack Type | Printed Bag |
| Package Hanging | No |
| Package EAN | 5050765201278 |
Case Inner
| Unpacked Height (mm) | 54 |
| Unpacked Width (mm) | 24.8 |
| Unpacked Depth (mm) | 25.8 |
| Minimum Box Depth (mm) | 25 |
| Front Plate Material Thickness (mm) | N/A |
Case Outer
| Packed Width (mm) | 75 |
| Packed Depth (mm) | 28 |
| Packed Height (mm) | 110 |
| Packed Gross Weight (kg) | 0.023 |
| Package Pack Type | Printed Bag |
| Package Hanging | No |
| Package EAN | 5050765201278 |
Container
| Packed Width (mm) | 75 |
| Packed Depth (mm) | 28 |
| Packed Height (mm) | 110 |
| Packed Gross Weight (kg) | 0.023 |
| Package Pack Type | Printed Bag |
| Package Hanging | No |
| Package EAN | 5050765201278 |
